Wood like honeycomb panel

Fengshun Aluminum honeycomb panelapply alloy aluminum panel, Ti alloy panel, stainless steel panel and etc. as the material of surface and bottom panel and aluminum honeycomb core in the middle, the honeycomb lay structural panel was made after high temperature and strongpress.It has the feature of fight. high strength, good hardness, sound proof and hot proof. Honeycomb panel is the material of aeronautics andastronautics,itis gradualy used in the feld of civilian nowadays such as construction, Vehicles, bilboard and other trades. Fengshun companyhas brought in the automatic complex manufacturing line from Germany, applied the double-component hot glue coating complex technology.so that the traditional manual single-plate production method has been changed, the production efficiency has increased and the quality oproducts has reached the intemational advanced level. at the same time, a variety of curved surface panel shape can fuly achieve the perfectcreativity of architect.

Specialty of the products

1.It has the high strength which can withstand more than 8000N/m2 of wind load.

2.Good hardness and light weight reduce a great deal of support loading of building.

3.Good sound-proofing, air sound insulation factor is 29 dB.

4.Good thermal insulation and fire resistance, thermal conductivity is 0.1613 W/(m-K)

5.High surface smoothness, be easy to install.

6.Wide varieties, single curved plate, double curved plate and etc. sketch plate.

Material and construction

Surface panel: alloy aluminum panel, Ti alloy panel, stain-less steel panel, etc.Core material: apply six angles 3003 type aluminum honey-comb side core. Aluminum thickness: 0.04-0.06mm, length:5-6mm. The core consists of many crowded interconnectinghoneycombs, just as many small H-beams which can with-stand dispersedly the pressure came from the direction ofsurface panel, with the help of this structure, strength ofwithstanding pressure and high surface smoothness are

ensured.Adhesive: imported German Henkel adhesive.

General thickness: 8 mm, 10 mm, 12 mm, 15 mm, 20 mm, 25 mm

Product application

Interior and exterior decoration of buildings (wallboard, ceiling, roof, ground structur-al materials, etc.); rail transit vehicle body, interior decoration series; ship, ship hullor interior decoration, etc.
